RollerChunQiu

YZC303

发布时间:2016-01-26来源:青峰集团点击:242

YZC303

The tandem vibratory rollers are small-size tandem vibratory roller, applied to mending and maintaining various roads, expressway shoulder, side walk , parking area, sports ground and garden lawn. They are especially suited for compaction of narrow areas as pipeline channel and drainage trench etc.

Main features:

1.Mechanical travel drive, hydraulic vibration and steering with reliable performance, easy operation and good function/worth ratio.

2.Reliable and powerful Changchai engine with large power reservation, reliable, performance, stable quality, low oil consumption and convenient in operation and maintenance.

3.Compact design of small size and beautiful appearance, suited for compaction of the narrow areas.

4.Scrapers and sprinkling devices on all drums for improving quality of construction.

5.Driver’s canopy is made from pergola adopt umbrella clothes or fiber reinforced plastics.

6.Platform trailer as option.

Main specifications:

MODELYZC303
Operating Mass3000 kg
Staic Linear Load153 120 N/cm
Vibration Frequency50 Hz
Exciting Force32 kn
Travel Speed2/5/8 km/h
Gradeability20%
Dimension(L×W×H)2880×1275×2650
Vibration Drum Width1090 mm
Drum diameter780 mm
Minimum turning radius4500 mm
Wheelbase2050 mm
Min. ground clearance260 mm
Diesel Capacity60L
Diesel ModelZN385Q
Diesel Power22 kw
Water Tank Capacity90 L
